Eaton Tripp Lite AVR750U 750VA 450W Line-Interactive UPS, 12 NEMA 5-15R Outlets, AVR, 120V 50/60 Hz, USB, Desktop/Wall Mount
Eaton Tripp Lite AVR750U 750VA 450W Line-Interactive UPS, 12 NEMA 5-15R Outlets, AVR, 120V 50/60 Hz, USB, Desktop/Wall Mount
Eaton Tripp Lite AVR750U 750VA 450W Line-Interactive UPS, 12 NEMA 5-15R Outlets, AVR, 120V 50/60 Hz, USB, Desktop/Wall Mount
AVR750U | TC-AVR750U
Please sign in to view pricing and availability and to add to cart.
Product Overview
AVR Series Line-Interactive UPS System offers ultra-compact, line-interactive protection for PCs and workstations. System maintains 120 volt nominal output over an input range of 83 to 147 volts. Workstation-optimized features include USB port (HID-PDC compliant), single-line telephone/DSL surge suppression, space saving right-angle input plug, six battery/surge-protected outlets and six additional surge-only outlets (12 total). USB port (included cable) works with free unattended shutdown software. Housing is mountable.
Main Features
General Information
Specifications
ADI Part Number TC-AVR750U Brand Name Eaton Tripp Lite Manufacturer Tripp Lite by Eaton Manufacturer Part Number AVR750U Packaged Quantity 1 Product Model AVR750U Product Name AVR 750VA Desktop UPS Product Series AVR Product Type Line-interactive UPS
Application/Usage ATM, Blu-ray Player, Computer, Digital Signage, Gaming Console, Home Theater, Home/Office, Media Center, Printer, Router, Security System, TV AVR Yes Backup/Run Time (Full Load) 3-Minute Backup/Run Time (Half Load) 11-Minute Dataline Protection RJ-11 EMI/RFI Noise Filter Yes Energy Saving Greater than 95% efficiency - GREEN UPS Number of Battery & Surge Outlets 6 Number of Surge-only Outlets 6 Output Voltage 110V AC, 115V AC, 120V AC Phase Single Phase Receptacle Detail 12 x NEMA 5-15R Receptacle Type NEMA 5-15R Transfer Time 6 ms
DC System Voltage 12 V DC Replaceable Battery Yes
Status Indicators 2 Status LEDs; GREEN indicates power status and operating mode / RED indicates battery-low, overload, replace-battery and fault conditions
Maximum Operating Elevation 10000 ft Maximum Operating Temperature 104°F (40°C)
Alarm Battery Backup, Fault, Low Battery, Overload, Replace Battery
Color Black Depth 12" Form Factor Tower, Ultra-compact Desktop, Wall Mount Height 4.1" Weight 15.84 lb Width 7.5"
Input Frequency 60 Hz Input Voltage 120V AC Output Frequency 60 Hz Plug/Connector Type NEMA 5-15R Surge Energy Rating 316 J Waveform Type Pulse-width Modulated Sine Wave
Limited Warranty 2-Year
Country of Origin CN Environmental Certification RoHS Package Contents - AVR 750VA Desktop UPS
- USB cable
- Instruction manual
