Hanwha TNO-C3012TRA T Series QVGA Radiometric AI Thermal Camera, 4.4mm Fixed Lens, IP66, IK10, White
TNO-C3012TRA|SQ-TC3012TRA
Hanwha TNO-C3012TRA T Series QVGA Radiometric AI Thermal Camera, 4.4mm Fixed Lens, IP66, IK10, White
TNO-C3012TRA|SQ-TC3012TRA
Hanwha Vision
Hanwha TNO-C3012TRA T Series QVGA Radiometric AI Thermal Camera, 4.4mm Fixed Lens, IP66, IK10, White
TNO-C3012TRA | SQ-TC3012TRA
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The Hanwha TNO-C3012TRA T Series Thermal Camera offers AI-driven object classification, identifying persons and vehicles with precision. Equipped with a high-performance 17µm detector and NETD 30mK, it delivers clear QVGA resolution (384x288) and a wide 90° field of view. This model supports an extensive temperature monitoring range from -40° to 550°C (-40°F to 1,022°F). Designed compact and lightweight (Φ147 * 233.5mm, 1.7KG), it ensures easy installation. It also supports up to 8fps across all resolutions using H.265/H.264/MJPEG. Upgrade your surveillance with reliable thermal imaging technology today!
Main Features
General Information
Name:Hanwha TNO-C3012TRA T Series QVGA Radiometric AI Thermal Camera, 4.4mm Fixed Lens, IP66, IK10, White
Category:Hanwha Vision, Video Surveillance, IP Cameras, Thermal Imaging Cameras, ADI Pro Rewards
UPC Code:8801089226709
Country of Origin:Korea, Republic of. Country of origin is subject to change.
Specifications
ADI Part Number SQ-TC3012TRA Brand Name Hanwha Vision Manufacturer Part Number TNO-C3012TRA Product Name TNO-C3012TRA Radiometric AI Thermal Camera Product Series T Product Type Network Camera
Field of View H: 90° / V: 65.3° / D: 118.6°(iFoV: 3.9 mRad) Lens Type Fixed Maximum Aperture f/1 Maximum Frame Rate 8fps Video Formats H.264, H.265, MJPEG Video Resolution 768 x 576
Image Sensor Type Uncooled Microbolometer
Ingress Protection Rating IP66
Maximum Video Resolution 1600 x 1200
Maximum Operating Temperature 140°F (60°C) Minimum Operating Temperature -40°F (-40°C) Operating Humidity 0.95
Maximum Thermal Focal Length 4.32mm
Color White Durability Dustproof, Impact Resistant, Waterproof Form Factor Bullet Weight 3.75lb
Input Voltage 12V DC
Diameter 3.7" Mount Type Backbox Mount
Limited Warranty 5-Year
Features Audio Detection, Digital Image Stabilization, Mirror, Motion Detection, Multi-view Stream, Privacy Masking, Sound Detection, Tampering Alarm, Temperature Sensor, Video Management System Impact Protection Rating IK10
