Product Overview
The GRI 129A style switch set is designed for those installations where a more esthetic profile is required. The attractive snap-on cover makes the 129A perfect for residential and light commercial applications. The cover also comes with knockout points if the wiring requires surface mount and the base is designed for taking the wire out directly into the wall if needed. Available in standard and wide gaps, White, Brown or Gray, the 129A set comes in closed and open loop with all mounting hardware included.
INSTALLATION APPLICATIONS:
The G.R.I. 129A style switch set is designed for those installations where a more aesthetic profile is required. The attractive snap-on cover makes the 129A perfect for residential and light commercial applications. The cover also comes with knockout points if the wiring requires surface mount, and the base is designed for taking the wire out directly into the wall if needed. Available in standard and wide gaps, White, Brown or Gray, the 129A set comes in closed and open loop with all mounting hardware included.
General Information
Name : GRI 129A 1/2" Miniature Surface Mount Switch Set, Standard Gap, Closed Loop, 10W, Reed Fom, Brown , George Risk Industries
Category : Magnetic Contacts
UPC Code : 697625004034
Country of Origin : US. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : GI-129AB
Brand Name : GRI
Manufacturer : George Risk Industries
Manufacturer Part Number : 129A-B
Product Model : 129A-B
Product Name : 129A-B Magnetic Contact
Product Series : 129
Product Type : Magnetic Contact
Technical Information
Contact Configuration : N.O.
Contact Form : Form A
Contact Resistance : 150000 Micro Ohm
Contact Resistance (Ohm) : 0.15
Mounting Type : Surface Mount
Standard Gap : 0.5"
Standard Gap (mm) : 12.7
Termination Style : Screw Terminal
Camera
Connectivity Technology : Wired
Physical Characteristics
Application/Usage : Commercial, Residential
Color : Brown
Power Description
Power Source : DC
Product Information
Contact Type : Closed Loop
Installation Type : Hybrid
Warranty
Limited Warranty : Lifetime
Limited Warranty (Second) : Lifetime
Miscellaneous
Additional Information : <ul> <li>Perfect For Residential and Light Commercial Applications</li> <li>Hermetically Sealed</li> <li>Plated Contacts Resist Sticking or Freezing</li> </ul>
Certifications & Standards : <ul> <li>UL</li> <li>ULC</li> </ul> <p></p>
Country of Origin : US
Features : Tamper Proof
Package Contents : <ul> <li>129A-B Magnetic Contact</li> <li>Covers</li> <li>Spacers</li> <li>Mounting Hardware</li> </ul>
