DITEK DTK-DR120P1 DIN Rail Surge Protective Device for Machine Control Panels
DTK-DR120P1|DK-DR120P1
DITEK DTK-DR120P1 DIN Rail Surge Protective Device for Machine Control Panels
DTK-DR120P1|DK-DR120P1
DITEK
DITEK DTK-DR120P1 DIN Rail Surge Protective Device for Machine Control Panels
DTK-DR120P1 | DK-DR120P1
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The DTK-DR Series of DIN-Rail surge protectors are designed to provide point-of-use protection for machine control panels and similar applications in commercial and industrial environments. The DTK-DR120P1 protects 120VAC single phase panels.
- Each model provides a 75,000 Amp/phase surge current rating to ensure powerful protection and a long service life
- Visual and remote end-of-life indicators enable proactive maintenance and the highest level of machine and system protection
- Compact, modular design for easy integration within machine control panels
- Approved for UL508 control panels
Main Features
General Information
Name:DITEK DTK-DR120P1 DIN Rail Surge Protective Device for Machine Control Panels
Category:DITEK, Batteries & Power Supplies, Power Strips & Surge Protectors, Surge Protection Modules
UPC Code:782980520234
Country of Origin:Mexico. Country of origin is subject to change.
Specifications
ADI Part Number DK-DR120P1 Brand Name DITEK Manufacturer DITEK Corporation Manufacturer Part Number DTK-DR120P1 Product Model DTK-DR120P1 Product Name DTK-DR120P1 Surge Supressor/Protector Product Series DTK-DR Product Type Surge Suppressor/Protector Sector Video Surveillance
NDAA Compliant Yes TAA Compliant Yes
Receptacles Hardwired
Color Red Height 2.8" Width 0.7"
Input Voltage 120V AC
Limited Warranty 5-Year
Country of Origin MX Environmental Certification RoHS Environmentally Friendly Yes
