AV Pro Edge AC-CX42-AUHD ConferX 4x2 HDMI Matrix Switcher with HDBaseT and Scaling
AC-CX42-AUHD|8A-ACCX42AUH
AV Pro Edge AC-CX42-AUHD ConferX 4x2 HDMI Matrix Switcher with HDBaseT and Scaling
AC-CX42-AUHD|8A-ACCX42AUH
Overview
Specifications
Documents
Product Overview
The ConferX 4x2 Matrix is a versatile 4K matrix switcher designed for conference rooms, classrooms, or huddle spaces, enabling any four sources to be displayed via independent HDBaseT and HDMI outputs. It supports HDMI 2.0 with 18 Gbps bandwidth, 4K60 4:4:4 video quality including HDCP 2.3 compliance, and offers advanced EDID management along with additional audio inputs and outputs. This matrix includes two HDBaseT inputs compatible with ConferX Wall Plate Transmitters extending signal reach up to 100 meters, facilitating seamless integration with microphone and intercom systems. Control options include an intuitive web-based GUI, auto-switching, and compatibility with major control systems such as Control4, Crestron, and Savant. The product is CE Certified, RoHS Compliant, and meets Prop65 warning requirements.
Main Features
General Information
Name:AV Pro Edge AC-CX42-AUHD ConferX 4x2 HDMI Matrix Switcher with HDBaseT and Scaling
Category:AV Pro Edge, Pro AV, Commercial Video Signal Distribution, Pro HDMI Switchers
UPC Code:850001710824
Country of Origin:China. Country of origin is subject to change.
Specifications
ADI Part Number 8A-ACCX42AUH Brand Name AV Pro Edge Manufacturer Part Number AC-CX42-AUHD
Operating Temperature (T-T) 23-125°F
HDMI Yes
