AXIS M4317-PLR 6MP Fisheye Panoramic Bullet IP Camera
AXIS M4317-PLR 6MP Fisheye Panoramic Bullet IP Camera
AXIS M4317-PLR 6MP Fisheye Panoramic Bullet IP Camera
02833-001 | Z4-02833001
Please sign in to view pricing and availability and to add to cart.
Product Overview
Optimized for surveillance onboard buses, this discreet, panoramic camera is designed to withstand shock and vibrations. It delivers a complete 180° or 360° overview for total situational awareness. Thanks to built-in IR illumination with individually controllable LEDs, it ensures clear, reflection-free footage and excellent image quality even in low light or complete darkness. Delivered factory-focused, it includes digital roll functionality to remotely adjust the rotation of the camera overview. Furthermore, this high-performance camera includes built-in cybersecurity features to help prevent unauthorized access and safeguard your system. Plus, it supports advanced analytics based on deep learning on the edge.
Main Features
General Information
Specifications
ADI Part Number Z4-02833001 Brand Name AXIS Communications Manufacturer Part Number 02833-001 Product Name AXIS M4317-PLR Product Series M43 Product Type Fixed dome cameras Supported Network Protocols IPv6 USGv6, NIST SP500-267
Aperture f/2.2 Effective Camera Resolution 6MP Field of View Horizontal, Vertical Maximum Frame Rate 60fps Night Vision Yes
Connectivity Technology Wired Image Sensor Type CMOS Wide Dynamic Range Yes
Ingress Protection Rating IP66
Image Sensor Size 1/1.8" Maximum Video Resolution 2160 x 2160
Minimum Illumination 0.03 lux
Certifications ECE R10 rev.06, EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), IEC 62236-4, KS C 9832 Class A, KS C 9835, RCM AS/NZS CISPR 32 Class A, VCCI Class A
Focal Length 1.1mm
Memory Card Supported Yes
Color White Durability Vandal Resistant Form Factor Dome
Maximum Power Consumption 13W Power over Ethernet (PoE) Yes
Certifications & Standards ONVIF G, ONVIF M, ONVIF S, ONVIF T Country of Origin MX Environmental Certification IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC TR 60721-4-5 Class 5M3 (Vibration, Shock), IEC/EN 60529 IP66, IEC/EN 61373 Category 1 Class B, IEC/EN 62262 IK10, ISO 21207 (Method B), ISO 4892-2, NEMA 250 Type 4X, NEMA TS 2 (2.2.7-2.2.9) Impact Protection Rating IK10
