Product Overview
The XAP-1610 is built with leading edge 802.11ac Wave 2 technology which offers support for more connected devices and increased data rates, delivering outstanding WiFi performance. It is compatible with all Luxul WiFi controllers, both standalone and embedded, and can be used standalone or as part of a multi- AP deployment. Installation is simple, requiring only a single Ethernet cable that delivers both power and data through the integrated PoE+ port.
- High performance 802.11ac WiFi (data transfers up to 3167Mbps)
- Concurrent Dual-Band Wireless AC
- 2.4 and 5GHz Beamforming
- High output power for maximum coverage
- Compatible with Luxul Roam Assist™ Wireless Controllers
- VLAN support for creating a secure guest network
- Simple and discreet installation
- Up to 4 SSIDs per band for a total of 8 SSIDs
- Single cable installation with PoE (Injector included)
- Great for streaming media or other demanding applications
- Installs on ceiling or wall; or use as a desktop AP
- Three-year limited warranty
- Supports 128 clients
- Wave 2 technology (MU-MIMO)
General Information
Name : HI PWR WAVE 2 AC 3100 DUAL WAP , Luxul by Legrand
Category : Wireless Access Points
UPC Code : 655003920970
Country of Origin : China. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : LW-XAP1610IC
Brand Name : Luxul
Manufacturer : Legrand Group
Manufacturer Part Number : XAP-1610-IC
NDAA Compliant : Yes
Packaged Quantity : 1
PoE+ (RJ-45) Ports : Yes
Product Line : Apex
Product Model : XAP-1610
Product Name : Apex Wave 2 AC3100 Dual-Band Access Point
Product Type : Wireless Access Point
Weight (Approximate) (g) : 680
Technical Information
Beamforming Technology : Yes
Data Encryption : Yes
MIMO Technology : Yes
Network Band : Dual Band
Power Consumption : 26 W
Total Number of Antennas : 4
Wireless LAN Standard : IEEE 802.11ac
Wireless Transmission Speed : 3.17 Gbit/s
Wireless Transmission Speed (Bps) : 425067544.576
Interfaces/Ports
Number of Network (RJ-45) Ports : 2
PoE PD Port : Yes
Network & Communication
Ethernet Technology : Gigabit Ethernet
Physical Characteristics
Depth : 7.3"
Depth (mm) : 184.912
Form Factor : Ceiling Mount, Desktop, Standalone, Wall Mount
Height : 1.7"
Height (mm) : 43.434
Weight (Approximate) : 680 g
Width : 7.3"
Width (mm) : 184.912
Power Description
Power Consumption (W) : 26.000
Tuner
Frequency Band : 2.40 GHz, 5 GHz
Frequency Band (Hz) : 2400000000, 5000000000
Warranty
Limited Warranty : 3 Year
Wireless Specifications
Encryption Standard : WPA, WPA2, WPA2-PSK, WPA-PSK
Miscellaneous
Country of Origin : China
Environmental Certification : RoHS
Environmentally Friendly : Yes
Indoor/Outdoor : Indoor
Package Contents : <ul> <li>Apex Wave 2 AC3100 Dual-Band Access Point</li> <li>Mounting Kit</li> <li>Rubber Feet</li> <li>PoE Injector </li> <li>Power Cord</li> <li>Ethernet Cable</li> <li>Quick Install Guide</li> </ul>
